Del Medical FWFC General Radiography System

Call for Pricing Email for Pricing

Prices subject to change

Description

Del Medical FWFC General Radiography System- economical system designed for small environments.   Economical system designed for small environments. The FWFC System offers an affordable, flexible solution designed for medical imaging centers and urgent care facilities looking to maximize space and minimize room modifications. Its secure floor and wall mounted rails allow for effortless longitudinal travel and quick positioning. This system is the most affordable radiographic system in the Del Medical product line, but its outstanding build quality and performance make it a perfect fit for low throughput facilities looking to enhance their diagnostic imaging capabilities. Compact Precision  The rotating tube stand offers exceptional versatility and accuracy. Its pressure activated 180° column rotation, centering detent, electric vertical and longitudinal locks, and 9″ transverse travel provide technologists with fast positioning and comprehensive accessibility.
Del Medical FWFC General Radiography System
Four-Way Float Top Table The RT100 table features a 700 lbs. patient weight capacity and a stain resistant floating table top which glides freely on a precision roller bearing system. Float top movements are safely controlled by heavy-duty electric locks, activated by a conveniently placed foot treadle release. The 17” x 17” standard bucky tray can accommodate any cassette sized detector with ease. Its all steel structure and welded base provides maximum strength and reliability. In addition, the RT100’s pedestal base can be used to store generator electronics making it a great space. The sturdy RT100 four-way float top table is suitable for use in a variety of general radiographic environments including small hospitals, clinics, ambulatory care centers and private offices. The table features a 700 lbs (318 kg) patient weight capacity and a stain resistant floating table top which glides freely on a precision roller bearing system. Float top movements are safely controlled by heavy-duty electric locks, activated by a conveniently placed foot treadle release. The 17” x 17” standard bucky tray can accommodate any cassette sized detector with ease. Its all steel structure and welded base provides maximum strength and reliability. In addition, the RT100’s pedestal base can be used to store generator electronics making it a great space saver.
Del Medical RT100 Four-Way Float Top Table
Options: Rotating Tray Cabinet The easy-to-use rotating tray enables one-handed operation supporting fast portrait-to-landscape rotation without removing the detector from the tray.
Del Medical Rotating Tray Cabinet
Table Side Hand grips These sturdy hand grips can be mounted along the entire length of both sides of the table top to enhance patient safety.
Del Medical Table Side Hand Grips
Lateral Cassette Holder This adjustable holder can be mounted along  both sides of the table top allowing for access to a variety of cross-table lateral views.
Del Medical Lateral Cassette Holder
Ergonomic Wall Stand The ultra compact VS100 upright is powered by an electric lock release handle and dual counterweight cables for added patient and user safety. Its expansive vertical travel of 58” (148 cm) enables a complete range of exams from skull to weight bearing knee and ankle exams.
Del Medical VS100 Upright Wall Stand

Specifications

FWFC Tube Stand:

Minimum ceiling height:        Minimum 96″ (244 cm) Vertical travel:            12″ (26.5 cm) to 73″ (189 cm) Longitudinal travel:    96″ (244 cm) with 8′ rail Transverse travel:      9″ (23 cm) Rail longitudinal length:        8′ standard, 12′ and 6′ optional Column rotation:        ±180° detents 0°, 90°, -90° Tube rotation: +180°, -180° ​

RT100 Table:

​Patient load capacity:           700 lbs. (317 kg) Table base length:    43″ (109 cm) Table base width:     29″ (74 cm) Total tabletop movement:    Longitudinal, 51.50″ (131 cm) Transverse, 9.5″ (24 cm) Tabletop-to-film distance:    3.25″ (8 cm) Total bucky travel:    Longitudinal, 11.25″ (28 cm) Tabletop length:        86.66″ (220 cm) Tabletop width:         32″ (81 cm) Weight:           387 lbs. (176 kg) Power requirements:            120/230-240 VAC Options:         – 78″ (198 cm) tabletop length – 32″ (81 cm) tabletop width – Lateral cassette holder – Table-side patient hand grips – Rotating cassette tray – Compression band

VS100 Wall Stand:

Height (w/ vertical travel):      86″ (220.4 cm) Depth:             13″ (33 cm) Receptor width:         23.3″ (59 cm) Receptor height:       23.4″ (59.4 cm) Weight (with receptor):        258 lbs. (117 kg) Max. focal spot height:          72.4″ (183.8 cm) Min. focal spot height:           14″ (35.6 cm) Power requirements:            24 VDC, 1.25 max. momentary amps

Multimedia

FWFC Brochure
