Delworks E14C 14x17in Wireless Detector

Call for Pricing Email for Pricing

Prices subject to change

Description

E14CE is an economical|portable 14″ x 17″ (35 cm x 43 cm) wireless detector with outstanding image quality|offering the compact versatility needed to optimize workflow.

DELWORKS EDR


Del Medical DELWORKS EDR
  Premium Options Available in Single, Dual, or Multi-Detector Applications   An intuitive and powerful DR retrofit system featuring lightweight detectors DELWORKS E-Series Wireless Detectors feature EasyConnect — an Auto Exposure Detection (AED) technology that keeps the detector in a standby mode, awaiting exposure from any X-ray source. Once an exposure is detected it instantly captures the X-ray image and transmits it wirelessly to the system workstation.

Specifications

The E14Ce is an economical, portable 14” x 17” (35 cm x 43 cm) wireless detector with outstanding image quality, offering the compact versatility needed to optimize workow. The E14Ce has an internal accelerometer which automatically senses motion and takes the detector in and out of ready mode, extending its battery life.

  • Scintillator       Cesium Iodide (CsI)
  • High Image Quality with spatial resolution of 148 μm Limiting resolution:3.5 lp/mm
  • Pixel matrix: 2400 x 2880
  • Wide active area of 13.8″ x 16.9″
  • Wireless transfer of data: 802.11a/b/g/n,2.4GHz/5GHz
  • EasyConnect AED (Automatic Exposure Detection) Needs no connection to an X-Ray Generator Detector AP Mode or Detector Only Mode
  • Dimensions:15″ x 18″ x 0.6″   Weight: 6.8 lbs. w/battery
  • Bit depth (A/D):16 bit A/D
  • Image display:3-6 sec.  Cycle time:9 sec. Exposure window:Up to 3.2 sec.
  • Battery: Li-Ion 3.35Ah 7.4V
  • DQE:70% @ 0 lp/mm, 51% @ 1 lp/mm, 42% @ 2 lp/mm, 29% @ 3 lp/mm
  • MTF:61% @ 1 lp/mm, 31% @ 2 lp/mm, 15% @ 3 lp/mm
  • 1 Year Warranty

Acquisition Workstation

Del Medical DELWORKS Acquisition Workstation

PRODUCT CODE: DELWORKSAWS

DELWORKS is a powerful image acquisition and processing software featuring a user-friendly interface that provides sophisticated and speedy medical imaging. Designed with complex system automation, DELWORKS aims to simplify the examination process by making the difficult decisions for you.

Its advanced anatomical programming and image processing algorithms help optimize technologist productivity. DELWORKS strives to minimize human error and unwanted repeat exams to give technologists high quality images at a lower dose, with every exposure.

DELWORKS

Acquisition and Processing Software Pre-exposure display of patient and procedure information, X-ray generator exposure factors, status and control functions integrated in a single display screen.

  • Exam-specific image processing algorithms automatically optimize images based on selected patient anatomy.
  • Enhanced image processing parameters. APR specific default values and manual adjustment, if desired.
  • Image rotation in 90° steps, horizontal mirroring, automatic and manual image cropping to collimated area.
  • Easy verification and correction of image laterality and patient orientation.
  • Intuitively add orientation markers and text comments directly to acquired images(pre-defined or free text).
  • Detailed histograms of pixel density User selection of modified LUT (Look-Up Table) based on various exam types.
  • Manual adjustment of the LUT, window and level, effectively manage rejected images.
Dow

.

DELWORKS Image Stitching

PRODUCT CODE: DRIS

This image has an empty alt attribute; its file name is Stitching.png
Del Medical DELWORKS Image Stitching

The optional image stitching application requires no unnecessary preprogramming or additional equipment, making full-length spine studies effortless and accurate.
